Continuous Inkjet Printers

High Speed 1610 Dual Head Continuous Inkjet Printer

  • 5-line CIJ printing Machine best for Batch coding



    With core life of 12,000 hours Videojet continuous inkjet printer 1610 comes with 2 printheads which have a capacity of 5 lines per print head. This CIJ machine comes with positive air flow features which help to keep the head clean with 0 downtime on production line. It is easy to use plug and play setup which means you will be up and running in few minutes.

  • Speed without compromising quality:


    • Dynamic Calibration™ adjusts jetting parameters automatically to help ensure high quality print

    • Dual printheads enable high speed printing of up to 10 lines of text with single printhead speed performance:Single line max speed = 293 m/min (960 ft/min)
      Dual line max speed = 146 m/min (480 ft/min)
      Tri-line max speed = 81 m/min (265 ft/min)


    Engineered for extended runs; Uptime Advantage via:


    • CleanFlow™ technology resists ink buildup that can cause ordinary inkjet printers to shut down

    • Long run time between preventive maintenance; up to 12,000 hour core life

    • Internal pump means no external air, minimizing potential for contaminants to enter ink stream

    • Auto cleaning printhead for fast start-ups, even after extended shutdowns


    No mess, no waste fluid delivery:


    • Make-up consumption as low as 2.4 ml/hour

    • Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used


    Simple Usability via Videojet standard CIJ interface:


    • Bright display with WYSIWYG and function keys for easy operation

    • User levels to separate operation from installation and maintenance

    • Prompted user fields to help reduce coding errors

  • Specifications
    Value
    Display (User Interface)
    SIMPLICiTY™ based 10 inch color touchscreen
    Positive Air / CleanFlow™
    Optional
    Linear and 2D Bar Codes
    Included
    Communications
    Ethernet LAN™; Built-in Wi-Fi; optional Cellular connectivity
    USB
    Included
    Plug and Play Printhead Modules
    Included
    Smart Cartridge™
    Included
    Message Storage Capability
    More than 250 complex messages
    Umbilical Length
    3 m (9.8 ft) optional 6 m (19.6 ft)
    Environmental Protection
    IP55 (Dust Kit IP65 #)
    Maximum Line Speed (1)
    278 m/min (914 ft/min)
    Maximum Lines of Print per Printhead
    5
    Inks
    Dye Based
    Printheads
    1
    Download Full Spec Sheet
