Continuous Inkjet Printers
High Speed 1610 Dual Head Continuous Inkjet Printer
5-line CIJ printing Machine best for Batch coding
With core life of 12,000 hours Videojet continuous inkjet printer 1610 comes with 2 printheads which have a capacity of 5 lines per print head. This CIJ machine comes with positive air flow features which help to keep the head clean with 0 downtime on production line. It is easy to use plug and play setup which means you will be up and running in few minutes.
Speed without compromising quality:
Dynamic Calibration™ adjusts jetting parameters automatically to help ensure high quality print
Dual printheads enable high speed printing of up to 10 lines of text with single printhead speed performance:Single line max speed = 293 m/min (960 ft/min)
Dual line max speed = 146 m/min (480 ft/min)
Tri-line max speed = 81 m/min (265 ft/min)
Engineered for extended runs; Uptime Advantage via:
CleanFlow™ technology resists ink buildup that can cause ordinary inkjet printers to shut down
Long run time between preventive maintenance; up to 12,000 hour core life
Internal pump means no external air, minimizing potential for contaminants to enter ink stream
Auto cleaning printhead for fast start-ups, even after extended shutdowns
No mess, no waste fluid delivery:
Make-up consumption as low as 2.4 ml/hour
Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used
Simple Usability via Videojet standard CIJ interface:
Bright display with WYSIWYG and function keys for easy operation
User levels to separate operation from installation and maintenance
Prompted user fields to help reduce coding errors
- SpecificationsValueDisplay (User Interface)SIMPLICiTY™ based 10 inch color touchscreenPositive Air / CleanFlow™OptionalLinear and 2D Bar CodesIncludedCommunicationsEthernet LAN™; Built-in Wi-Fi; optional Cellular connectivityUSBIncludedPlug and Play Printhead ModulesIncludedSmart Cartridge™IncludedMessage Storage CapabilityMore than 250 complex messagesUmbilical Length3 m (9.8 ft) optional 6 m (19.6 ft)Environmental ProtectionIP55 (Dust Kit IP65 #)Maximum Line Speed (1)278 m/min (914 ft/min)Maximum Lines of Print per Printhead5InksDye BasedPrintheads1
